DIN 2527 PN40 Blind Flanges Manufacturer and Supplier in Jakarta, Indonesia

In Jakarta, Indonesia, Ismail Flanges is a reputable manufacturer and supplier of DIN 2527 PN40 Blind Flanges, providing precisely engineered flanges for high-pressure applications. Our PN40 blind flanges are made to safely close pipe ends in systems that operate at pressures of up to 40 bar and are designed in compliance with DIN 2527 standards. These flanges, which are made from premium materials, guarantee excellent resistance to temperature and pressure, long-lasting durability, and leak-proof sealing. Serving industries such as oil & gas, petrochemicals, water treatment, and power generation, Ismail Flanges delivers dependable flange solutions tailored to meet both local and international project requirements.

DIN 2527 PN40 Standards Blind Flanges in Indonesia, DIN 2527 PN40 Blind Plate Flange in Surabaya, Raised Face DIN 2527 PN40 Blind Flanges in Surabaya, Stainless Steel DIN 2527 PN40 Blind Flanges in Bandung, DIN 2527 PN40 Blind Pipe Flange in Indonesia, Best Price of DIN 2527 PN40 Blind Flanges Manufacturer in Jakarta.

Stainless Steel DIN 2527 PN40 Blind Flanges

Alloy Steel DIN 2527 PN40 Blind Flanges

Alloy 20 DIN 2527 PN40 Blind Flanges

The high-strength materials used to make DIN 2527 PN40 Blind Flanges include alloy steels, carbon steel (C22.8 or A105), and stainless steel (304/316). These materials are chosen according to the pressure and temperature requirements of the application. These flanges are appropriate for high-pressure systems because of their PN40 pressure rating, which is 40 bar or approximately 580 psi. Tensile strength ranges from 485 to 620 MPa, yield strength ranges from 250 to 450 MPa, and it exhibits good resistance to corrosion and heat stress. These flanges are perfect for harsh settings where pipe ends must be securely sealed under high operating pressures.

Monel DIN 2527 PN40 Blind Flange in Jakarta, Hastelloy DIN 2527 PN40 Blind Flanges in Indonesia, Titanium DIN 2527 PN40 Blind Flanges in Indonesia, SS DIN 2527 PN40 Blind Flanges Stockist in Surabaya, Nickel Alloy DIN 2527 PN40 Blind Flanges in Surabaya, Inconel DIN 2527 PN40 Blind Flanges in Bandung, Alloy Steel DIN 2527 PN40 Blind Flanges, Duplex Steel DIN 2631 Blind Flange, Carbon Steel DIN 2527 PN40 Blind Flanges in Bekasi.

DIN 2527 PN40 Blind Flanges Specification

Size Chart	1/2″ (15 NB) To 48″ (1200NB)
Coating Flanges Faces	Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint
Design For Size	DIN, EN, ASA, PN, JIS, BS, ANSI, ASME
Pressure Rating Table	Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS
Supporting Flanges Material	Flanges Bolts, Gasket, Ring Joint
Connect Type Type	FF, RTJ, SMF, LMF, RF, LJF
Production Process	Forged, Heat Treated and Machined
Standard	ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange
Machining Equipment	Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc

DIN 2527 PN40 Blind Flanges Dimensions

DIN 2527 PN40 (in mm)
Nominal Pipe Size	Flanges Dia	Thk of Flange	Dia of Bolt Circle	No. of	Dia of Bolt Holes
DIN	D	B	K	holes	D2	KG
10	90	16	60	4	14	0.72
15	95	16	65	4	14	0.81
20	105	18	75	4	14	1.14
25	115	18	85	4	14	1.38
32	140	18	100	4	18	2.03
40	150	18	110	4	18	2.35
50	165	20	125	4	18	3.20
65	185	22	145	8	18	4.29
80	200	24	160	8	18	5.54
100	235	24	190	8	22	7.60
125	270	26	220	8	26	10.82
150	300	28	250	8	26	14.60
175	350	32	295	12	30	22.04
200	375	34	320	12	30	27.21
250	450	38	385	12	33	44.38
300	515	42	450	16	33	64.17
350	580	46	510	16	36	89.52
400	660	50	585	16	39	126.76
500	755	56	670	20	42	184.63
600	890	62	795	20	48	285.17
700	995	64	900	24	48	368.83
800	1140	70	1030	24	56	528.39
900	1250	76	1140	28	56	690.99
1000	1360	84	1250	28	56	912.42

Largest DIN 2527 PN40 Blind Flanges Supplier in Indonesia, Jakarta

Ismail Flanges, a leading supplier in Indonesia, Jakarta, offers an extensive selection of DIN 2527 PN40 Blind Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.

Contact us to get a quick quote for your requirement.

We offer These Flanges as per DIN, ISO, JIS or ANSI Standard.

DIN 2527 PN40 Blind Flanges are primarily used to seal the ends of pipelines, valves, and pressure vessels in high-pressure systems. They are crucial in industries such as oil and gas, petrochemical, chemical processing, and water treatment, where they help isolate sections of pipelines during maintenance, repairs, or system modifications. These flanges provide reliable, leak-proof closures, ensuring the integrity and safety of the system. Their high strength and durability make them ideal for applications that require secure sealing in demanding, high-pressure environments.

DIN 2527 PN40 Blind Flanges Stockist in Indonesia, DIN 2527 PN40 Blind Flanges Supplier in Surabaya, DIN 2527 PN40 Blind Flanges Supplier in Indonesia, DIN 2527 PN40 Blind Flanges Stockist in Bekasi, DIN 2527 PN40 Blind Flanges Manufacturer in MM, DIN 2527 PN40 Blind Flanges Manufacturer in Jakarta.

Types of DIN 2527 PN40 Blind Flanges

Are Custom Sizes Available for DIN 2527 PN40 Blind Flanges?

Yes, we offer custom sizes for DIN 2527 PN40 Blind Flanges to meet specific project needs. Our team at Ismail Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ismailflanges.id.

DIN 2527 PN40 Blind Flanges Size Chart

NPS NPS (inch)
NPS NPS (inch)	Diammeter of Flange (inch)	No. of Bolts	Diammeter of Bolts (inch)	Diammeter of Bolt Holes (inch)	Bolt Circle (inch)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Widest Range of DIN 2527 PN40 Blind Flanges in Jakarta.

DIN 2527 PN40 Blind Pipe Flanges Wholesaler	DIN 2527 PN40 BLRF Flanges Supplier
Carbon Steel Raised Face DIN 2527 PN40 Blind Flange Stockist	Duplex Steel DIN 2527 PN40 BLRF Flanges Supplier in Surabaya
Stainless Steel DIN 2527 PN40 Blind Flange	ASTM B564 Raised Faced DIN 2527 PN40 Blind Flanges
DIN 2527 PN40 Large Diameter Blind Flange	30 Inch DIN 2527 PN40 Blind Pipe Flange Dimensions
30 inch DIN 2527 PN40 Blind Flange Dealer	Raised Face DIN 2527 PN40 Blind Flanges Manufacturer
DIN 2527 PN40 Blind Pipe Flanges Supplier in Indonesia	Duplex Steel DIN 2527 PN40 Blind Flanges
4 inch Stainless Steel DIN 2527 PN40 Blind Flange	DIN 2527 PN40 Blind RF Flanges Stockholder
Carbon Steel DIN 2527 PN40 Blind Flange	DIN 2527 PN40 Blind RF Flange Supplier
Alloy Steel DIN 2527 PN40 Blind Flanges	Copper Nickel DIN 2527 PN40 Blind Flanges at Best Price
DIN 2527 PN40 Blind Flange Dimensions	Raised Face DIN 2527 PN40 Blind Flange Manufacturer
Raised Face DIN 2527 PN40 Blind Plate Flanges	Titanium DIN 2527 PN40 Blind Flanges
Nickel Alloy DIN 2527 PN40 Blind Flange	Mild Steel DIN 2527 PN40 Blind Flange
DIN 2527 PN40 BLRF Flanges Distributor in Indonesia	Flat Face DIN 2527 PN40 Blind Flanges Exporter
DIN 2527 PN40 BLRF Flange Stockist in Jakarta	Raised Faced DIN 2527 PN40 Slip-On flanges Dealer in Bekasi
18 inch DIN 2527 PN40 Carbon Steel Blind Flange	DIN 2527 PN40 Blind Flange Dimensions in mm
DIN 2527 PN40 Blind Flanges Supplier in Indonesia	MS DIN 2527 PN40 Blind Flange
8 Inch DIN 2527 PN40 Blind Pipe Flanges	DIN 2527 PN40 Blind Flanges Stockist
DIN 2527 PN40 BLRF Flanges Supplier in Surabaya	Alloy Steel DIN 2527 PN40 Blind Flanges Manufacturer in Jakarta
ASME SA105N Raised Faced DIN 2527 PN40 Blind Flanges	18 inch Carbon Steel DIN 2527 PN40 Blind Flange
German Standard DIN 2527 PN40 Blind Flanges	DIN 2527 PN40 Blind Flange Supplier in Bekasi
DIN 2527 PN40 Blind FF Flange Supplier	Suppliers of DIN 2527 PN40 Blind Flange
DIN 2527 PN40 Blind Flange Manufacturer	Flat Face DIN 2527 PN40 Blind Flange Manufacturer
DIN 2527 PN40 BLRF Flange Exporter	DIN 2527 PN40 Blind Flange Pressure Ratings

Material Testing

We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
