Ismail Flanges, based in Jakarta, Indonesia, stands out as a top manufacturer and supplier of high-quality DIN 2631 PN6 Weld Neck Flanges. Known for their precision engineering and commitment to international standards, the company provides flanges that deliver exceptional performance across a range of industrial applications. Their DIN 2631 PN6 Weld Neck Flanges are specifically crafted for low-pressure piping systems, boasting impressive strength, durability, and resistance to leaks under both thermal and mechanical stress. Catering to sectors like petrochemical, water treatment, food processing, and HVAC systems, Ismail Flanges promises timely delivery, competitive pricing, and dependable service throughout Indonesia and beyond.
Ismail Flanges produces DIN 2631 PN6 Weld Neck Flanges using top-notch materials such as carbon steel, stainless steel (AISI 304/316), and alloy steels. The chemical makeup ensures both corrosion resistance and structural integrity. These flanges feature mechanical properties like a tensile strength ranging from 415 to 620 MPa, a minimum yield strength of 250 MPa, and an elongation of 20%. With a nominal pressure rating of PN6, they are perfect for low-pressure systems. Their long tapered hub design helps distribute stress evenly between the flange and the pipe, minimizing stress concentration and enhancing fatigue resistance during thermal cycles.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Pipe | Flange | Neck | Raised face | Screws | Weight | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (7,85 Kg/dm3) | ||||||||||||||||
| Rated | d1 | D | b | k | h1 | d3 | s | r | h2 | d4 | f | Holes | Thread | d2 | Kg | |
| Diameter | ISO Series | DIN Series | ||||||||||||||
| 15 | – | 20 | 80 | 12 | 55 | 30 | 28 | 2 | 4 | 6 | 40 | 2 | 4 | M 10 | 11 | 0,392 |
| 21,3 | – | 30 | ||||||||||||||
| 20 | – | 25 | 90 | 14 | 65 | 32 | 35 | 2,3 | 4 | 6 | 50 | 2 | 4 | M 10 | 11 | 0,592 |
| 26,9 | – | 38 | ||||||||||||||
| 25 | – | 30 | 100 | 14 | 75 | 35 | 40 | 2,6 | 4 | 6 | 60 | 2 | 4 | M 10 | 11 | 0,747 |
| 33,7 | – | 42 | ||||||||||||||
| 32 | – | 38 | 120 | 14 | 90 | 35 | 50 | 2,6 | 6 | 6 | 70 | 2 | 4 | M 12 | 14 | 1,05 |
| 42,4 | – | 55 | ||||||||||||||
| 40 | – | 44,5 | 130 | 14 | 100 | 38 | 58 | 2,6 | 6 | 7 | 80 | 3 | 4 | M 12 | 14 | 1,18 |
| 48,3 | – | 62 | ||||||||||||||
| 50 | – | 57 | 140 | 14 | 110 | 38 | 70 | 2,9 | 6 | 8 | 90 | 3 | 4 | M 12 | 14 | 1,34 |
| 60,3 | – | 74 | ||||||||||||||
| 65 | 76,1 | – | 160 | 14 | 130 | 38 | 88 | 2,9 | 6 | 9 | 110 | 3 | 4 | M 12 | 14 | 1,67 |
| 80 | 88,9 | – | 190 | 16 | 150 | 42 | 102 | 3,2 | 8 | 10 | 128 | 3 | 4 | M 16 | 18 | 2,71 |
| 100 | – | 108 | 210 | 16 | 170 | 45 | 122 | 3,6 | 8 | 10 | 148 | 3 | 4 | M 16 | 18 | 3,24 |
| 114,3 | 130 | |||||||||||||||
| 125 | – | 133 | 240 | 18 | 200 | 48 | 148 | 4 | 8 | 10 | 178 | 3 | 8 | M 16 | 18 | 4,49 |
| 139,7 | – | 155 | ||||||||||||||
| 150 | – | 159 | 265 | 18 | 225 | 48 | 172 | 4,5 | 10 | 12 | 202 | 3 | 8 | M 16 | 18 | 5,15 |
| 168,3 | – | 184 | ||||||||||||||
| 200 | 219,1 | – | 320 | 20 | 280 | 55 | 236 | 5,9 | 10 | 15 | 258 | 3 | 8 | M 16 | 18 | 7,78 |
| 250 | – | 267 | 375 | 22 | 335 | 60 | 282 | 6,3 | 12 | 15 | 312 | 3 | 12 | M 16 | 18 | 10,8 |
| 273 | – | 290 | ||||||||||||||
| 300 | 323,9 | – | 440 | 22 | 395 | 62 | 342 | 7,1 | 15 | 15 | 365 | 4 | 12 | M 20 | 22 | 14 |
| 350 | 355,6 | – | 490 | 22 | 445 | 62 | 385 | 7,1 | 12 | 15 | 415 | 4 | 12 | M 20 | 22 | 18,5 |
| – | 368 | 16,7 | ||||||||||||||
| 400 | 406,4 | – | 540 | 22 | 495 | 65 | 438 | 7,1 | 12 | 15 | 465 | 4 | 16 | M 20 | 22 | 21,2 |
| – | 419 | 19 | ||||||||||||||
| 500 | 508 | – | 645 | 24 | 600 | 68 | 538 | 7,1 | 12 | 15 | 570 | 4 | 20 | M 20 | 22 | 28,6 |
| 600 | 610 | – | 755 | 24 | 705 | 70 | 640 | 7,1 | 12 | 16 | 670 | 5 | 20 | M 24 | 26 | 31,5 |
| 700 | 711 | – | 860 | 24 | 810 | 70 | 740 | 7,1 | 12 | 16 | 775 | 5 | 24 | M 24 | 26 | 37,4 |
| 800 | 813 | – | 975 | 24 | 920 | 70 | 842 | 7,1 | 12 | 16 | 880 | 5 | 24 | M 27 | 30 | 46,1 |
| 900 | 914 | – | 1075 | 26 | 1020 | 70 | 942 | 7,1 | 12 | 16 | 980 | 5 | 24 | M 27 | 30 | 55,6 |
| 1000 | 1016 | – | 1175 | 26 | 1120 | 70 | 1045 | 7,1 | 16 | 16 | 1080 | 5 | 28 | M 27 | 30 | 61,9 |
Ismail Flanges, a leading supplier in Indonesia, Jakarta, offers an extensive selection of DIN 2631 PN6 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Ismail Flanges’ DIN 2631 PN6 Weld Neck Flanges are extensively utilized in industries that demand leak-proof connections in low-pressure pipelines. Typical applications include water distribution systems, sewage treatment facilities, chemical processing, food and beverage piping, and HVAC setups. The tapered hub design adds extra strength at high-stress points, making them ideal for handling thermal expansion and cyclic loading. These flanges are the go-to choice in scenarios where pipe bending and mechanical stresses are prevalent. They come in a variety of sizes and material grades to meet the specific needs of different projects.
Yes, we offer custom sizes for DIN 2631 PN6 Weld Neck Flanges to meet specific project needs. Our team at Ismail Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ismailflanges.id.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| Nickel Alloy DIN 2631 PN6 Welding Neck Flange | Mild Steel DIN 2631 PN6 Weld Neck Flange |
| Carbon Steel DIN 2631 PN6 Welding Neck Flange | DIN 2631 PN6 Weld Neck RF Flange Supplier in Jakarta |
| DIN 2631 PN6 Weld Neck Flange Dimensions | Raised Face DIN 2631 PN6 Weld Neck Flange Manufacturer |
| 18 inch DIN 2631 PN6 Carbon Steel Weld Neck Flange | DIN 2631 PN6 Weld Neck Flange Dimensions in mm |
| Alloy Steel DIN 2631 PN6 Welding Neck Flanges | Copper Nickel DIN 2631 PN6 Weld Neck Flanges at Best Price |
| DIN 2631 PN6 Welding Neck FF Flange Supplier | Suppliers of DIN 2631 PN6 Weld Neck Flange |
| German Standard DIN 2631 PN6 Weld Neck Flanges | DIN 2631 PN6 Weld Neck Flange Supplier in Bekasi
|
| DIN 2631 PN6 Weld Neck Flange Manufacturer | Flat Face DIN 2631 PN6 Weld Neck Flange Manufacturer |
| DIN 2631 PN6 WNRF Flange Stockist in Jakarta | Raised Faced DIN 2631 PN6 welding-neck flanges Dealer in Jakarta |
| Stainless Steel DIN 2631 PN6 Weld Neck Flange | ASTM B564 Raised Faced DIN 2631 PN6 Weld Neck Flanges |
| DIN 2631 PN6 WNRF Flange Exporter | DIN 2631 PN6 Weld Neck Flange Pressure Ratings |
| Raised Face DIN 2631 PN6 Weld Neck Plate Flanges | Titanium DIN 2631 PN6 Welding Neck Flanges |
| DIN 2631 PN6 WNRF Flanges Supplier in Surabaya | Alloy Steel DIN 2631 PN6 Weld Neck Flanges Manufacturer in Jakarta |
| DIN 2631 PN6 Weld Neck Pipe Flanges Supplier in Indonesia | Duplex Steel DIN 2631 PN6 Weld Neck Flanges |
| 4 inch Stainless Steel DIN 2631 PN6 Weld Neck Flange | DIN 2631 PN6 Weld Neck RF Flanges Stockholder |
| DIN 2631 PN6 Welding Neck Flanges Supplier in Indonesia | MS DIN 2631 PN6 Weld Neck Flange |
| 30 inch DIN 2631 PN6 Weld Neck Flange Dealer | Raised Face DIN 2631 PN6 Weld Neck Flanges Manufacturer |
| 8 Inch DIN 2631 PN6 Welding Neck Pipe Flanges | DIN 2631 PN6 Weld Neck Flanges Stockist |
| Carbon Steel Raised Face DIN 2631 PN6 Weld Neck Flange Stockist | Duplex Steel DIN 2631 PN6 WNRF Flanges Supplier in Indonesia |
| ASME SA105N Raised Faced DIN 2631 PN6 Weld Neck Flanges | 18 inch Carbon Steel DIN 2631 PN6 Weld Neck Flange |
| DIN 2631 PN6 Weld Neck Pipe Flanges Wholesaler | DIN 2631 PN6 WNRF Flanges Supplier |
| DIN 2631 PN6 Large Diameter Weld Neck Flange | 30 Inch DIN 2631 PN6 Weld Neck Pipe Flange Dimensions |
| DIN 2631 PN6 WNRF Flanges Distributor in Indonesia | Flat Face DIN 2631 PN6 Weld Neck Flanges Exporter |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
