DIN 2632 PN10 Weld Neck Flanges Manufacturer and Supplier in Jakarta, Indonesia

Ismail Flanges is a reputable manufacturer and supplier of DIN 2632 PN10 Weld Neck Flanges, proudly located in Jakarta, Indonesia. These flanges are crafted to meet strict DIN standards, ensuring secure, leak-proof connections in pipelines that operate under moderate pressures. Ismail Flanges provides a variety of DIN 2632 PN10 Weld Neck Flanges made from carbon steel, stainless steel, and alloy grades, all precisely machined for perfect alignment and robust weld joints. With state-of-the-art forging facilities, a talented engineering team, and thorough quality control processes, the company delivers dependable products that are widely utilized in water supply, petrochemical, HVAC, and industrial sectors.

DIN 2632 PN10 Welding Neck Flanges Stockist in Indonesia, DIN 2632 PN10 Weld Neck Flanges Supplier in Surabaya, DIN 2632 PN10 Weld Neck Flanges Supplier in Indonesia, DIN 2632 PN10 Welding Neck Flanges Stockist in Bekasi, DIN 2632 PN10 Weld Neck Flanges Manufacturer in MM, DIN 2632 PN10 WNRF Flanges Manufacturer in Jakarta.

Stainless Steel DIN 2632 PN10 Weld Neck Flanges

Alloy Steel DIN 2632 PN10 Weld Neck Flanges

Alloy 20 DIN 2632 PN10 Weld Neck Flanges

Typically, DIN 2632 PN10 Weld Neck Flanges are made from carbon steel grades like S235JR and ASTM A105, as well as stainless steels such as 304 and 316, depending on the specific service conditions. Carbon steel flanges offer tensile strengths ranging from 360 to 600 MPa and a yield strength of about 235 MPa, providing good ductility and weldability. On the other hand, stainless steel options enhance corrosion resistance with tensile strengths reaching up to 700 MPa. Designed for the PN10 pressure class (10 bar / ~145 psi), these flanges ensure excellent sealing and structural integrity in low- to medium-pressure pipelines. The long tapered hub design promotes smooth stress distribution and minimizes fatigue.

DIN 2632 PN10 Standards Weld Neck Flanges in Indonesia, DIN 2632 PN10 Weld Neck Plate Flange in Surabaya, Raised Face DIN 2632 PN10 WNRF Flanges in Surabaya, Stainless Steel DIN 2632 PN10 Weld Neck Flanges in Bandung, DIN 2632 PN10 Welding Neck Pipe Flange in Indonesia, Best Price of DIN 2632 PN10 Weld Neck Flange Manufacturer in Jakarta.

DIN 2632 PN10 Weld Neck Flanges Specification

Size Chart	1/2″ (15 NB) To 48″ (1200NB)
Coating Flanges Faces	Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint
Design For Size	DIN, EN, ASA, PN, JIS, BS, ANSI, ASME
Pressure Rating Table	Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS
Supporting Flanges Material	Flanges Bolts, Gasket, Ring Joint
Connect Type Type	FF, RTJ, SMF, LMF, RF, LJF
Production Process	Forged, Heat Treated and Machined
Standard	ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange
Machining Equipment	Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc

DIN 2632 PN10 Weld Neck Flanges Dimensions

Germany standard flange DIN 2632 welding neck flanges; nominal pressure 10
Brides à souder à collerette DIN 2632: pression nominale 10
Pipe			Flange				Neck				Raised face		Screws			Weight
																(7,85 Kg/dm3)
Rated	d1		D	b	k	h1	d3	s	r	h2	d4	f	Holes	Thread	d2	Kg
Diameter	ISO Series	DIN Series
15	–	20	95	14	65	35	30	2	4	6	45	2	4	M 12	14	0,648
	21,3	–					32
20	–	25	105	16	75	38	38	2,3	4	6	58	2	4	M 12	14	0,952
	26,9	–					40
25	–	30	115	16	85	38	42	2,6	4	6	68	2	4	M 12	14	1,14
	33,7	–					45
32	–	38	140	16	100	40	52	2,6	6	6	78	2	4	M 16	18	1,69
	42,4	–					56
40	–	44,5	150	16	110	42	60	2,6	6	7	88	3	4	M 16	18	1,86
	48,3	–					64
50	–	57	165	18	125	45	72	2,9	6	8	102	3	4	M 16	18	2,53
	60,3	–					75
65	76,1	–	185	18	145	45	90	2,9	6	10	122	3	4	M 16	18	3,06
80	88,9	–	200	20	160	50	105	3,2	8	10	138	3	8	M 16	18	3,7
100	–	108	220	20	180	52	125	3,6	8	12	158	3	8	M 16	18	4,62
	114,3	–					131
125	–	133	250	22	210	55	150	4	8	12	188	3	8	M 16	18	6,3
	139,7	–					156
150	–	159	285	22	240	55	175	4,5	10	12	212	3	8	M 20	22	7,75
	168,3	–					184
200	219,1	–	340	24	295	62	235	5,9	10	16	268	3	8	M 20	22	11,3
250	–	267	395	26	350	68	285	6,3	12	16	320	3	12	M 20	22	14,7
	273	–					292
300	323,9	–	445	26	400	68	344	7,1	12	16	370	4	12	M 20	22	17,4
350	355,6	–	505	26	460	68	385	7,1	12	16	430	4	16	M 20	22	23,6
	–	368														21,6
400	406,4	–	565	26	515	72	440	7,1	12	16	482	4	16	M 24	26	28,6
	–	419														26,2
(450)	457	–	615	28	565	72	488	7,1	12	16	532	4	20	M 24	26	31,5
500	508	–	670	28	620	75	542	7,1	12	16	585	4	20	M 24	26	38,1
600	610	–	780	28	725	80	642	7,1	12	18	685	5	20	M 27	30	44,6
700	711	–	895	30	840	80	745	8	12	18	800	5	24	M 27	30	62,4
800	813	–	1015	32	950	90	850	8	12	18	905	5	24	M 30	33	84,1
900	914	–	1115	34	1050	95	950	10	12	20	1005	5	28	M 30	33	98,5
1000	1016	–	1230	34	1160	95	1052	10	16	20	1110	5	28	M 33	36	115

Largest DIN 2632 PN10 Weld Neck Flanges Supplier in Indonesia, Jakarta

Ismail Flanges, a leading supplier in Indonesia, Jakarta, offers an extensive selection of DIN 2632 PN10 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.

Contact us to get a quick quote for your requirement.

We offer These Flanges as per DIN, ISO, JIS or ANSI Standard.

DIN 2632 PN10 Weld Neck Flanges are widely used in low to medium-pressure piping systems across industries such as oil and gas, petrochemicals, water treatment, and HVAC. These flanges provide secure, leak-proof connections between pipes, valves, and other equipment, ensuring system reliability. Their weld neck design minimizes stress at the connection points, making them ideal for applications with mild temperature and pressure fluctuations. Commonly used in pipelines and process systems, these flanges offer enhanced stability and alignment, helping maintain smooth operation and system integrity in critical applications.

Monel DIN 2632 PN10 WNRF Flange in Jakarta, Hastelloy DIN 2632 PN10 Weld Neck Flanges in Indonesia, Titanium DIN 2632 PN10 Welding Neck Flanges in Indonesia, SS DIN 2632 PN10 Weld Neck Flanges Stockist in Surabaya, Nickel Alloy DIN 2632 PN10 Weld Neck Flanges in Surabaya, Inconel DIN 2632 PN10 WNRF Flanges in Bandung, Alloy Steel DIN 2632 PN10 Weld Neck Flanges, Duplex Steel DIN 2631 Weld Neck Flange, Carbon Steel DIN 2632 PN10 Welding Neck Flanges in Bekasi.

Types of DIN 2632 PN10 Weld Neck Flanges

Are Custom Sizes Available for DIN 2632 PN10 Weld Neck Flanges?

Yes, we offer custom sizes for DIN 2632 PN10 Weld Neck Flanges to meet specific project needs. Our team at Ismail Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ismailflanges.id.

DIN 2632 PN10 Weld Neck Flanges Size Chart

NPS NPS (inch)
NPS NPS (inch)	Diammeter of Flange (inch)	No. of Bolts	Diammeter of Bolts (inch)	Diammeter of Bolt Holes (inch)	Bolt Circle (inch)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Widest Range of DIN 2632 PN10 Weld Neck Flanges in Jakarta.

18 inch DIN 2632 PN10 Carbon Steel Weld Neck Flange	DIN 2632 PN10 Weld Neck Flange Dimensions in mm
Alloy Steel DIN 2632 PN10 Welding Neck Flanges	Copper Nickel DIN 2632 PN10 Weld Neck Flanges at Best Price
DIN 2632 PN10 Weld Neck Flange Dimensions	Raised Face DIN 2632 PN10 Weld Neck Flange Manufacturer
DIN 2632 PN10 Welding Neck FF Flange Supplier	Suppliers of DIN 2632 PN10 Weld Neck Flange
DIN 2632 PN10 Weld Neck Pipe Flanges Wholesaler	DIN 2632 PN10 WNRF Flanges Supplier
30 inch DIN 2632 PN10 Weld Neck Flange Dealer	Raised Face DIN 2632 PN10 Weld Neck Flanges Manufacturer
Nickel Alloy DIN 2632 PN10 Welding Neck Flange	Mild Steel DIN 2632 PN10 Weld Neck Flange
DIN 2632 PN10 WNRF Flange Stockist in Jakarta	Raised Faced DIN 2632 PN10 welding-neck flanges Dealer in Bekasi
Raised Face DIN 2632 PN10 Weld Neck Plate Flanges	Titanium DIN 2632 PN10 Welding Neck Flanges
German Standard DIN 2632 PN10 Weld Neck Flanges	DIN 2632 PN10 Weld Neck Flange Supplier in Jakarta
Stainless Steel DIN 2632 PN10 Weld Neck Flange	ASTM B564 Raised Faced DIN 2632 PN10 Weld Neck Flanges
DIN 2632 PN10 WNRF Flange Exporter	DIN 2632 PN10 Weld Neck Flange Pressure Ratings
DIN 2632 PN10 Weld Neck Flange Manufacturer	Flat Face DIN 2632 PN10 Weld Neck Flange Manufacturer
DIN 2632 PN10 WNRF Flanges Supplier in Indonesia	Alloy Steel DIN 2632 PN10 Weld Neck Flanges Manufacturer in Bekasi
DIN 2632 PN10 Welding Neck Flanges Supplier in Bandung	MS DIN 2632 PN10 Weld Neck Flange
DIN 2632 PN10 Large Diameter Weld Neck Flange	30 Inch DIN 2632 PN10 Weld Neck Pipe Flange Dimensions
Carbon Steel Raised Face DIN 2632 PN10 Weld Neck Flange Stockist	Duplex Steel DIN 2632 PN10 WNRF Flanges Supplier in Indonesia
ASME SA105N Raised Faced DIN 2632 PN10 Weld Neck Flanges	18 inch Carbon Steel DIN 2632 PN10 Weld Neck Flange
DIN 2632 PN10 WNRF Flanges Distributor in Surabaya	Flat Face DIN 2632 PN10 Weld Neck Flanges Exporter
DIN 2632 PN10 Weld Neck Pipe Flanges Supplierin Indonesia	Duplex Steel DIN 2632 PN10 Weld Neck Flanges
8 Inch DIN 2632 PN10 Welding Neck Pipe Flanges	DIN 2632 PN10 Weld Neck Flanges Stockist
4 inch Stainless Steel DIN 2632 PN10 Weld Neck Flange	DIN 2632 PN10 Weld Neck RF Flanges Stockholder
Carbon Steel DIN 2632 PN10 Welding Neck Flange	DIN 2632 PN10 Weld Neck RF Flange Supplier

Material Testing

We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
