Ismail Flanges is a trusted manufacturer and supplier of Titanium Flat Flanges, proudly based in Jakarta, Indonesia. They specialize in providing top-notch flange solutions tailored for demanding industrial applications. Renowned for their corrosion-resistant and lightweight products, Ismail Flanges ensures that their Titanium Flat Flanges adhere to strict international standards. Crafted from high-grade titanium using cutting-edge production techniques, these flanges are built for durability and precision. With a strong commitment to quality, timely delivery, and exceptional customer service, Ismail Flanges has gained the confidence of clients in the chemical, marine, aerospace, and medical sectors, solidifying its position as a key player in the flange manufacturing industry.
Titanium Flat Flanges are primarily made from commercially pure titanium (Grade 2 or Grade 5), boasting over 99% titanium content along with trace amounts of elements like iron, carbon, nitrogen, and oxygen. This unique composition grants them outstanding corrosion resistance and an impressive strength-to-weight ratio. Mechanically, these flanges showcase a tensile strength of around 550 MPa, a yield strength of approximately 485 MPa, and an elongation of up to 20%. Their lightweight design, excellent fatigue resistance, and ability to withstand extreme temperatures make Titanium Flat Flanges the perfect choice for critical and corrosive environments across various industries.
| Product Name | Titanium Flat Flanges |
|---|---|
| Size Range | 1/2″ (15 NB) to 48″ (1200NB) |
| Class / Pressure Rating | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standards / Dimensions | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, BS, GOST, MSS SP-44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605 |
| Titanium Flat Face Flanges / Connection Type | Flat Face Flange (FF), Raised Face Flange (RF), Ring Joint Flange (RTJ), Lap Joint Flange, Male and Female Flange (M&F), Large and Small Tongue-and-Groove Flange (T&G) |
| Dimensions | ANSI B16.5, ANSI B16.47 Series A & B, ASA, API-605, MSS SP44, AWWA, Custom Drawings |
| Custom Design | As per your drawing | AS, BS, ANSI, DIN, JIS | Equal and Reducing Configurations |
| Material Test Certificates (MTC) | As per EN 10204 3.2 and EN 10204 3.1, Test Certificates certifying NACE MR0175, NACE MR0103 |
| Test Certificates | 100% Radiography Test Report, EN 10204/3.1B, Raw Materials Certificate, Third Party Inspection Report, etc |
| Tests | Hydrostatic testing machine, Direct-reading Spectrograph, UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment / Machines | Press machine, Pushing Machine, Bending machine, Sand-blasting machine, electric bevelling machine, etc. |
Ismail Flanges, a leading supplier in Indonesia, Jakarta, offers an extensive selection of Titanium Flat Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
These flanges find extensive use in sectors that demand lightweight, corrosion-resistant, and high-performance components. In the marine industry, they excel in seawater applications thanks to their exceptional resistance to saltwater corrosion. The aerospace sector appreciates their strength-to-weight ratio, making them ideal for structural joints. In chemical processing, Titanium Flat Flanges are essential for systems that handle corrosive acids and gases. Medical and pharmaceutical applications benefit from their biocompatibility and non-reactive nature. Moreover, power plants and desalination units rely on these flanges in high-temperature, corrosive environments for reliable performance.
| STANDARD | UNS | WERKSTOFF NR. |
| Titanium Gr 2 | R50400 | 3.7035 |
| Titanium Gr 5 | R56400 | 3.7165 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 1 | .08 Max | .03 Max | .18 Max | .015 Max | Bal | .20 Max |
| Titanium Grade 4 | .08 Max | .05 Max | .40 Max | .015 Max | Bal | .50 Max |
| Titanium Grade 7 | .08 Max | .03 Max | .25 Max | .015 Max | Bal | .30 Max |
| Titanium Grade 9 | .08 Max | .03 Max | .15 Max | .015 Max | – | .25 Max |
| Titanium Grade 12 | .08 Max | .03 Max | .25 Max | 0.15 Max | – | .30 Max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 4.5 G/Cm3 | 1665 °C (3030 °F) | Psi – 39900 , MPa – 275 | Psi – 49900 , MPa – 344 | 20 % |
| 4.43 G/Cm3 | 1632 °C (2970 °F) | Psi – 128000 , MPa – 880 | Psi – 138000 , MPa – 950 | 14 % |
Yes, we offer custom sizes for Titanium Flat Flanges to meet specific project needs. Our team at Ismail Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ismailflanges.id.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
