Titanium Plate Flanges Manufacturer and Supplier in Jakarta, Indonesia

Ismail Flanges, a leading manufacturer and supplier in Jakarta, Indonesia, provides precision-engineered Titanium Plate Flanges for various high-performance applications. These flat, circular flanges connect pipes, valves, or equipment in systems where corrosion resistance and strength are essential. Made from high-grade titanium, they are lightweight but very durable, making them perfect for marine, chemical, and aerospace industries. They are easy to install and compatible with standard piping systems. Titanium Plate Flanges from Ismail Flanges meet international standards, ensuring reliable quality, leak-proof connections, and long-lasting performance in demanding environments.

Titanium Plate Flanges Price List in Indonesia, Titanium Plate Flanges Supplier in Indonesia, Titanium Plate Flange Dealer in Surabaya, Titanium Plate Flanges Supplier in Surabaya, Titanium Loose Plate Flanges Exporter in Surabaya, Titanium Plate Flanges Size Chart, Titanium Plate Flanges Price in Bandung, Titanium Loose Plate Flanges Thickness, Titanium Plate Flanges Supplier in Bekasi, Titanium Plate Flanges Stockist in Indonesia, Titanium Loose Plate Flanges Exporter in Jakarta

Titanium Loose Plate Flanges

Titanium Raise Face Plate Flanges

Titanium Flat Face Plate Flanges

Titanium Plate Flanges are usually made from commercially pure titanium (Grade 2) or titanium alloys like Grade 5 (Ti-6Al-4V). Grade 2 offers great corrosion resistance and weldability, with a tensile strength of about 345 MPa and high ductility. Grade 5 provides even greater strength (up to 895 MPa), fatigue resistance, and heat stability. Both grades resist chlorides, seawater, and many aggressive chemicals. Titanium’s low density (4.5 g/cm³), high melting point, and non-magnetic features make these flanges suitable for lightweight, high-stress applications in corrosive or high-temperature settings.

Titanium Plate Flanges Supplier in Indonesia, Titanium Plate Flanges Weight Chart, Titanium Plate Flanges Flanges Exporter in Indonesia, Titanium Loose Plate Flanges Manufacturer in Surabaya, Titanium Plate Flanges Price List in Bekasi, Titanium Plate Flanges Sizes in mm, Titanium Loose Plate Flanges Distributor in Surabaya, Titanium Plate Flanges in Bandung, Titanium Plate Flanges Distributor in Jakarta

Titanium Plate Flanges Specification

Specifications	ASTM B381 / ASME SB381
Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Grades	Titanium Gr. 1, Titanium Gr. 2, Titanium Gr. 4, Titanium Gr. 5, Titanium Gr. 7
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Size	1 / 2” to 18″
Class / Pressure	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Type	Plate Flanges

Chemical Composition of Titanium Plate Flanges

Grade	Ti	C	Fe	H	N	O	Al	V
Ti Grade2	99.2 min	0.1 max	0.3 max	0.015 max	0.03 max	0.25 max	–	–
Ti Grade5	90 min	–	0.25 max	–	–	0.2 max	6 min	4 min

Mechanical Properties of Titanium Plate Flanges

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Titanium Gr. 2	4.5 g/cm3	1665 °C (3030 °F)	Psi – 49900 , MPa – 344	Psi – 39900 , MPa – 275	20 %
Titanium Gr. 5	4.43 g/cm3	1632 °C (2970 °F)	Psi – 138000 , MPa – 950	Psi – 128000 , MPa – 880	14 %

Largest Titanium Plate Flanges Supplier in Indonesia, Jakarta

Ismail Flanges, a premier supplier in Indonesia, Jakarta, specializes in high-quality Titanium Plate Flanges. They are valued for their exceptional durability, corrosion resistance, precise engineering, and suitability across diverse industrial applications.

Contact us to get a quick quote for your requirement.

We offer These Flanges as per DIN, ISO, JIS or ANSI Standard.

Titanium Plate Flanges are commonly used in industries that need strong, corrosion-resistant connections, such as chemical processing, desalination, marine engineering, and aerospace. They are perfect for applications where low weight and high strength are critical, including seawater cooling systems, heat exchangers, and chemical transfer lines. In power plants and offshore structures, they function reliably under extreme pressure and corrosive conditions. Their flat design allows for easy bolting to pipe systems or equipment, creating secure, leak-proof connections. Additionally, their biocompatibility and resistance to contamination make them suitable for pharmaceutical, food processing, and medical-grade fluid systems.

Titanium Plate Flanges Price List in Indonesia, Titanium Loose Plate Flanges Supplier in Indonesia, Titanium Plate Flanges Exporter in Surabaya, ASME SB381 Titanium Plate Flange Exporter in Jakarta, Titanium Plate Flanges Exporter in Surabaya, ASTM B381 Loose Plate Flange in Bandung, Titanium Plate Flanges Size Chart, Titanium Loose Plate Flanges Price in Bandung, Titanium Alloy Plate Flanges Weight Chart, Titanium Plate Flanges Supplier in Bekasi, Titanium Plate Flanges Stockist in Indonesia

Types of Titanium Plate Flanges

Titanium Plate Flanges Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS
Titanium Gr. 2	3.7035	R50400
Titanium Gr. 5	3.7165	N56400

Are Custom Sizes Available for Titanium Plate Flanges?

Yes, we offer custom sizes for Titanium Plate Flanges to meet specific project needs. Our team at Ismail Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ismailflanges.id.

Material Testing

We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
